Single slip turnout EKW15, without turnout mechanisms. Standard design with internal switch rails.
Length 230 mm (standard length), crossing angle 15°, branch radius 531 mm.
For diagonal installation two D4 and one D12 are included.
Suitable turnout mechanisms (2 pieces are required):
40295 (electric turnout mechanism left)
or 40297 (manual turnout mechanism left)
or 10030 (below baseboard mechanism).
â– Frog and wheel guide completely revised
â– Prototypical passing of the frog possible
â– Groove width in the frog area according to NEM
â– Polarisation of the turnout frog possible in combination with electric ROCO turnout drives
| Specifications: |
| Measurements |
| Rail profile height |
|
02. Jan mm |
|
